Magnetic Chuck For Grinding Machine

Round Permanent Magnetic Chuck for Grinding Machine
1.Applies to surface grinder, EDM machine and linear cutting machine.
2.Pole space is fine, magnetic force is distributed uniformly. It performs well on thin and tiny workpiece machining. The working table precision doesn't change during magnetizing or demagnetizing.
3.The panel through special processing,with no leakage, prevents corrosion by cutting fluid, extends working life and enables to work longer time in cutting fluid.
4. Fine grinding on six faces. Can be used vertically in linear cutting machine.
5. The chuck with high performance magnetic steel, powerful magnetic force and almost no residual magnetism.

Model	D	H	K	C	C2	Z	M	P	Magnetic force	N.W.(kg)
X51 110	110	48	4	60	85	4	M8	1.5+0.5 or 3+1	120N/CM2	3.5
X51 130	130	48		80	110					4.8
X51 160	160	48	5	120	140					7.4
X51 200	200	53		160	180		M10			12.8
X51 250	250	53		200	224					20
X51 300	300	53		250	280		M12			32
X51 400	400	58		315	355					57
X51 500	500	65	6	400	450	8				100





Frequently asked Questions:

Q: Are you a trading company or a manufacturer?
We are a factory and trading company. We have many cooperative factories of different quality and price, just tell us what you need, there will always be something suitable for you.

Q: What is your delivery deadline?
We accept FOB, C&F, etc. You can choose the one that is most convenient or cost-effective for you.

Q: What is your lead time?
a: It usually takes 7-10 days if it's available, or 20-30 days if it's not. It depends on how much you order.

What are your terms of payment?
TT, credit card, letter of credit, Western Union, paypal, etc., we accept all kinds of payment methods.

Q: How many hours do you work?
A: Normally, our working hours are from 8:00 am to 17:00 PM Beijing time, but if you have an emergency, please feel free to contact us. Our sales staff will solve your problem as soon as possible

Hot Tags: magnetic chuck for grinding machine, China magnetic chuck for grinding machine manufacturers, suppliers, factory, 6 x 12 magnetic chuck
