Lifting Magnets For Cranes
PML Series: 100-6000 Kgs Permanent Magnetic Lifting(PML-A):
Permanent Magnetic Lifters are mainly used to lift steel plates, blocks, press molds, etc., and load / unload in machines during handling operations. They can hoist moving iron blocks and other magnetic materials. They are easy to operate and safe to handle and hence are widely used as lifting devices in factories, docks, warehouses, and transportation industries. By using them, you can improve your working conditions and increase your working efficiency.
| Model | Rated load(KG) | Applicable steel plate thickness(MM) | Maximum length of steel plate(MM) | Net weight(KG) | Dimensions(in) |
| 100KG | 100 | 5-25 | 500 | 2.6 | 3.58*2.44*2.67 |
| 200KG | 200 | 10-30 | 600 | 5.5 | 5.3*2.44*2.67 |
| 400KG | 400 | 20-40 | 800 | 9 | 6.37*3.46*3.62 |
| 600KG | 600 | 25-50 | 1000 | 18 | 8.46*4.05*4.56 |
| 1000KG | 1000 | 40-80 | 1300 | 27 | 9.52*5.11*5.19 |
| 2000KG | 2000 | 50-100 | 1800 | 58 | 13*5.82*6.53 |
| 3000KG | 3000 | 60-120 | 2300 | 75 | 15.7*5.82*6.53 |
| 5000KG | 5000 | 80-160 | 3000 | 188 | 20.74*8.85*8.66 |
Shipment:
1: Usually the net weight of magnets is below 100 KG, we suggest shipping by Air/Express.
2: If the net weight of magnets is about 100 KG, we suggest shipping by Sea.
Packing:
1: For Air/Express transport: several pieces of magnets in one box, 8 boxes in one carton, carton lined with foam box and iron sheets, outside of the carton with bubble paper.
2: For Sea transport: several pieces of magnets in one box, 8 boxes in one carton, a carton lined with foam box, and several cartons in one wooden carton/pallet.
PS: If you have a special packing request, pls let us know, and we will try to meet your requirements.
Q1. Can I have a sample order for a Neodymium magnet?
A: Yes, we welcome sample orders to test and check quality. Low MOQ, 1pc for sample checking is available. Mixed samples are acceptable. but do not pay the cost of freight.
Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 15~30 days for order in general.
Q3. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx, or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping are also optional.
Q4. Is it OK to print my logo on a magnet product or package?
A: Yes. Please inform us formally before our production and confirm the design first based on our sample.
Q5: How are Neodymium Magnets made?
A: The main ingredients are Neodymium, Iron, and Boron. The exact ingredients depend on the grade being produced. We also add a key ingredient called dysprosium to raise the coercivity of the material and increase the resistance to demagnetization and corrosion.
Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive prices to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
